Megelli 250SR

slide 1 slide 1 slide 1 slide 1 slide 1 slide 1

Specification



Engine
Type 4-strokes, Liquid Cooled
Cylinder Single
Displacement 249.6 cc
Compression Ratio 11.5 : 1
Valve Train 4V OHC
Max Power 26 hp / 8500 rpm
Max Torque 22.8 Nm / 7000 rpm
Lubrication System Forced and Wet Sump
Fuel Grade Unleaded
Transmission
Clutch Type Wet Types, Multi-Plates
Transmission 6 Speeds Gear Change
Gear
Gear Shift Pattern 1-N-2-3-4-5-6
Additional Information
Ignition System C.D.I
Starter System Electric Start
Carburetor TK MV34
Main Frame 13A Multi Twin Spar Trellis Configuration
Rear Swing Arm T6 Aluminium Trellis With Forged Dropout
Out Riggers T6 Aluminium Trellis Forged Twin Plate Bearing Carrier
Front Suspension Conventional
Rear Suspension Fast Ace
Final Drive Cushioned
Net Weight 122 Kg
Speedometer KOSO
Dimension
Seat Height 800 mm
Wheel Base 1350 mm
Wheel
Front Rim Aluminium 2.75 x 17
Rear Rim Aluminium 3.50 x 17
Front Tire Tubeless 100/70-17
Rear Tire Tubeless 130/70-17
